grouting pump from China manufacturer - Lead Equipment Co.,Ltd

Price:	8000.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: LGM130/20

Production Capacity: 1000sets/year

Delivery Date: 15 working days

Means of Transport: Ocean,Land,Air

Packing: veneer packing

color: customised

LGM130/20 Grouting pump Features:
1. Single piston double-acting
2. Gear&Vee belt transmission makes this pump high mechanical efficiency

LGM130/20 Medium-Pressure Grouting Pump

Grouting Pump

Grout Pump

Pump

LGM-130/20 Grouting Pump is a single piston double-acting grouting pump with gear reducer, which is a universal medium-pressure grouting pump. It is used for grouting in soil nails, earth anchors, cable and rock bolts, void fillings, dam foundations, foundation stabilization, tunnel lining, slope line grouting.

LGM130/20 Grouting pump Features:

1. Single piston double-acting

2. Gear&Vee belt transmission makes this pump high mechanical efficiency

and working reliability

3. Integrated valve house and ball valve, together with compact structure

4. Body of pump is made of aluminum casting, low weight is an advantage for transport

LGM 130/20 Grouting pump Main technical Data:

Rated Output	130L/min
Rated Pressure	2MPa(20bar/290psi)
Cylinder Dia.	75mm
Piston Stroke	85mm
Stroke/Minute	180/min
Inlet diameter	51mm
Outlet diameter	38mm
Power unit	5.5KW(Electric) 10hp(Diesel)
Transmission	V-belt+gearbox
Chassis	Skid
Weight	260kg
Overall Dimensions	1400x600x1000(mm)
